Surveying Instrument GPS RTK Base and Rover FOIF A70 PRO 800Channels GNSS GPSS RTK RECEIVER

Brand Name:	FOIF
Model Number:	A70 PRO
MOQ:	1 piece
Price:	$3,600.00
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

RTK Receiver FOIF A70 PRO Base And Rover

Customized Support:

Channel:

800Channels

Controller:

Waterproof:

Memory:

8GB, Support To 32GB

L1C/A,L1C,L2C,L2P,L5

GLONASS:

L1C/A,L2C/A,L2O,L5

Supply Ability:

1 ~ 30 day

Highlight:

gps rtk receiver

gnss rtk receiver

gnss rtk gps receiver

Product Description

Surveying Instrument GPS RTK Base and Rover FOIF A70 PRO 800Channels GNSS GPSS RTK RECEIVER

Specification

Model		A70 PRO
GNSS	Channels	394
	Signals	BDS: B1, B2, B3
		GPS: L1CA/L1P/L1C/L2P/L2C
		GLOASS: G1,G2, P1, P2
		GALILEO: E1BC, E5a, E5b
		QZSS: L1CA, L2C, L5, L1C
Accuracy	Static	H: 2.5 mm±1ppm , V: 5 mm±1ppm
	RTK	H: 8 mm±1ppm, V:15 mm±1ppm
	DGNSS	<0.5m
	ATLAS	8cm
System	Initialization Time	8s
	Initialization Reliable	0.999
	Operating System	Linux
	Merrory	8GB, support expanable MisroSD
	Wifi	802.11 b/g/n
	Bluetooth	V2.1+EDR/V4.1Dual,Class2
	Tilt Survey	don't support
Datalink	Audio	support TTS audio broadcast
	Protocol	support GeoTalk,SATEL,PCC-GMSK,TrimTalk,TrimMark,SOUTH
	Network	LTE FDD: B1/B3/B5/B8
		LTE TDD: B38/B39/B40/B41
		TD-SCDMA: B34/B39
		CDMA: BC0 WCDMA: B1/B8 GSM: 900/1800MHz
	output format	RTCM2.3, RTCM3.2, CMR, CMR+, ROX TCM3.2, CMR, CMR+, ROX
Physical	Interface	1*5Pin(Power & RS232);
		Type-C: For direct charging, data transmission;
		Sim card slot: Install SIM card
	Button	1 Power Button
	Indication Light	4 Indication Lights
	Size	148mm*62mm
	Weight	800g
Power supply	Battery capacity	Built-in Lithium-ion battery 7.2V/6700mAh.
	Life Timer	Up to 9 hours
	External power source	DC 9-18V, with overvoltage protection
Environment	Work Temporature	-35℃ ~ +65℃
	Storage Temporature	-55℃ ~ +80℃
	waterproof&dustproof	IP68
	Humidity	100% anti-condensation

Product Description

Our Services and Advantages

Services

1.Any inquiries will be replied within 12 hours.
2.All our products have one year warranty, And we sure the products will be free for maintenance within warranty period.
3.All products will have been strictly quality checked in factory before sending out.

Certifications

FAQ

1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),North America(4.00%),Eastern
Europe(4.00%). There are total about 11-20 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
