Surveying Instrument GPS RTK Base and Rover Unistrong G970C Pro/S631 Gps Rtk Gps Rove GNSS GPSS RTK RECEIVER

Brand Name:	Unistrong
Model Number:	G970C PRO
MOQ:	1 piece
Price:	$5,000.00
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

RTK Receiver Unistrong G970C PRO Base And Rover

Customized Support:

Channel:

1408 Channels

Color:

Yellow

Material:

Magnesium Alloy Shell

Galileo:

E1,E5a,E5b,ALTBOC,E6

L1C/A,L1C,L1P,L2C,L2P,L5

B1I,B2I,B3I,B1C,B2a,B2b,ACEBOC

Supply Ability:

1 ~ 30 day

Highlight:

gps rtk receiver

unistrong rtk receiver

unistrong rtk gps receiver

Product Description

Surveying Instrument GPS RTK Base and Rover Unistrong G970C PRO Gps Rtk Gps Rove GNSS GPSS RTK RECEIVER

Product Description

G970IIPro supports GPS, GLONASS, BDS, GALILEO and other systems to receive multi-frequency signals. The build-in "Lyra" baseband chip is able to provide more channels. The receiver supports "Atlas" L-Band signals and can achieve centimeter-level positioning. In addition, a new combination antenna is used to integrate GNSS, WiFi, Bluetooth and 4G to perform better in complex environments.
Product Features
- "Lyra" Baseband Chip
Integrated 800 channels,supporting multi-constellation and multi-frequency.
- Atlas
Supporting "Atlas" L-Band, with global centimeter-level positioning accuracy on a single receiver.
-Multi-communications network 4G
Built-in high-speed network module supporting Multi-network 2/3 / 4G.
-Tilt surveying 2.0
New tilt surveying algorithm makes easy coordinate collection.
-Combination Antenna
The new combination antenna integrates GNSS, WiFi, Bluetooth, and 4G with better wireless signal. The signal-to-noise ratio of GNSS satellites is increased by 2dB on average. Better RTK performance in complex environments.

Product Details

S631 GNSS Receiver Specifications
Number of channels	1408	394
Tracking characteristics	GPS: L1C/A,L1C,L1P,L2C,L2P,L5 BDS: B1I,B2I,B3I,B1C,B2a,B2b,ACEBOC GLONASS: G1,G2,G3 Galileo: E1,E5a,E5b,ALTBOC,E6 QZSS: L1C/A,L1C,L2C,L5,LEX SBAS	GPS: L1CA/L1P/L1C/L2P/L2C/L5 GLONASS: G1/G2, P1/P2 BeiDou: B1/B2 (B3 separate variant without L5) Galileo: E1BC/E5a/E5b QZSS: L1CA/L2C/L5/L1C
Accuracy indicators
Update rate	10Hz standard configuration, 20Hz/50Hz can be authorized	5Hz
Static accuracy	Horizontal: ± (2.5+1 × 10-6D) mm Vertical: ± (5+1 × 10-6D) mm
RTK accuracy	Horizontal: ± (8+1 × 10-6D) mm Vertical: ± (15+1 × 10-6D) mm
RTKFusion	30 ° rod tip positioning accuracy within 2cm, 60 ° rod tip positioning accuracy within 5cm Note: 1.8-meter pole height situation
Electrical performance
Battery characteristics	Dual battery, 7.2V/3400mAh * 2. At room temperature, the mobile station radio mode can support no less than 9 hours of operation.
input voltage	9~28V DC
system configuration
operating system	Linux
Built in storage	8G onboard; TF card extension, maximum support of ≥ 32G
Bluetooth	V5.0+EDR backward compatibility/BLE
WIFI	802.11 b/g/n
Network communication	GSM:900/1800MHz CDMA 1x/EVDO:BC0 WCDMA:B1 TD-SCDMA:B34/B39 FDD LTE:B1/B3/B8 TDD LTE:B38/B39/B40/B41
UHF radio station	TRM101: Power 1W, frequency 410-470MHz
Communication protocol	TrimTalk 450S, PCC GMSK, SATEL, HITARGET(9600), HITARGET(19200), TrimTalk(4800), HZSZ, South 9600, TrimMark III, South 19200, GEOTALK, GEOMARK
Tilt measurement	support
data interface
TNC	Connect the antenna of the built-in radio station.
5-core interface	Used to connect external power sources and external radio stations.
7-core interface	Used to connect PC or handheld devices, USB+serial port.
Other	SIM card slot and TF card slot, installing SIM card and TF card
man-machine interface
Keys	Power button, used to turn on and off the host. Short press once to report the current working mode and status.
Indicator light	Power supply (red green dual color)	Green constantly on: battery level 30% -100%; Green flashing: battery level 10% -30%;
	Satellite (red green dual color)	Off: No stars received; Flashing red light: received the star, but did not locate it successfully; Green light flashing:positioned but not fixed; Green light always on: fixed release; Flashing red and green lights alternately: GNSS motherboard abnormal.
	Bluetooth (blue monochrome)	Off: No Bluetooth connection established with the device; Chang Liang: Establish a Bluetooth connection with the device.
	Data link (green blue dual color)	Green light always on: The data link has been successfully set up; Green light flashing: normal data transmission; Blue light flashing: In static mode, the blue light flashes according to the set static sampling interval.
Voice	Support TTS voice broadcasting
physical characteristics
Integrated antenna	Integrated integrated antenna
Size	156mm*76mm
Weight	Approximately 1.2KG
Environmental performance
working temperature	-45℃ ～ +75℃
Storage temperature	-55℃ ～ +85℃
Waterproof and dustproof	IP68
Falling	It can withstand a drop of 2 meters from the pole at room temperature (on a hardwood ground), with a free drop of 1.2 meters.
Humidity	Anti 100% condensation

Surveying Instrument GPS RTK Base and Rover Unistrong G970C Pro/S631 Gps Rtk Gps Rove GNSS GPSS RTK RECEIVER 0

Certifications

FAQ

1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),North America(4.00%),Eastern
Europe(4.00%). There are total about 11-20 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
