Hemisphere S321/G10A Star station differential RTK GNSS receiver Equipped with UniStrong RTK control platform

Brand Name:	Unistrong
Model Number:	S321/G10A
MOQ:	1 piece
Price:	$1,500.00
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

RTK Receiver Unistrong Hemisphere S321/G10A

Customized Support:

Channel:

394 Channels

Brand Name:

Hemisphere/Unistrong

Color:

Black

Material:

Pure Magnesium Alloy

L1C/A,L1C,L2C,L2E

Power:

Two Lithium Batteries

Supply Ability:

1 ~ 30 day

Highlight:

rtk gnss receiver

receiver gps gnss rtk

unistrong rtk gnss

Product Description

Hemisphere S321/G10A Star station differential RTK GNSS receiver Equipped with UniStrong RTK control platform

Product Details

Satellite tracking
Beidou	B1,B2,B3
GPS	L1C/A,L1C,L2C,L2E
GLONASS	L1C/A,L1P,L2C/A,L2P
Galileo	E1,E5a,E5b
SBAS	WAAS,EGNOS,GAGAN,MSAS
Number of channels	394
positioning accuracy
Chinese precision	Plane: 5-12CM Elevation: 10-15CM
DGNSS	Plane: ± 0.25m+1ppm (RMS) Elevation: ± 0.5m+1ppm (RMS)
static state	Plane: ± 2.5mm+1ppm Elevation: ± 5mm+1ppm
RTK	＜30km Plane: ± 8mm+1ppm Elevation: ± 15mm+1ppm
RTK initialization time	＜10s
Tilt measurement (2m pole height)	10 ° inclination angle: 2cm 20 ° inclination angle: 3cm 30 ° inclination angle: 5cm
telecommunications
Radio station	Built in 2W integrated transceiver radio station
Radio operating frequency band	410MHz-470MHz
Network	WCDMA network communication, supporting HSDPA+, GPRS, GSM
Bluetooth	Bluetooth 2.1+EDR/Bluetooth 4.0BLE dual-mode Bluetooth
WIFI	802.11b/g/n, supports access point and client modes
Differential link	Supports built-in network, radio, external input, Bluetooth, and WiFi input
Differential format	CMR,CMR+ ,RTCM23,RTCM3.X
Physical indicators
Size	Φ14cm×14.4cm H
working temperature	-30℃ ~ +65℃
Storage temperature	-40℃ ~ +85℃
Protection	IP67
Humidity	100%
Impact resistance	2m dropped from the pole to the cement floor without damage
Electrical indicators
External power supply	DC 9V~22V (with overvoltage protection)
Battery capacity	11.1V 37.74WH intelligent battery
Battery usage time
Static	10h
UHF reference station	6h
UHF mobile station	8h
Network	6h
Storage
Internal storage	4G (supports up to 32G expansion)
Storage Expansion	MicroSD card storage expansion, supports up to 32GB
WebUI
WebUI	MicroSD card storage expansion, supports up to 32GB

Product Display

Customer Photos

Certifications

Company Profile

Our Service

Packing & Delivery
