International Version STONEX S700A/S3II Gps Surveying Instruments GNSS Rover And Base Station RTK

Brand Name:	STONEX
Model Number:	S700A/S3II
MOQ:	1 piece
Price:	$3,100.00
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

RTK Receiver STONEX S700A/S3II

Customized Support:

Channel:

800 Channels

Transmitting Power:

0.5W, 1W, 2W Adjustable

Transmitting Speed:

9.6Kbps, 19.2Kbps

L1 ,L2, L5

Working Range:

5km Typical, 8~10km Optimal

B1, B2, B3

Supply Ability:

1 ~ 30 day

Highlight:

stonex rtk gnss

stonex gnss rtk receiver

gps rtk gnss

Product Description

International Version STONEX S700A/S3II Gps Surveying Instruments GNSS Rover And Base Station RTK

Certifications

Company Profile

FAQ

1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),North America(4.00%),Eastern
Europe(4.00%). There are total about 11-20 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian

Our Service

Packing & Delivery

Tags:

Products Details

Home > Products >

GNSS RTK Receiver

International Version STONEX S700A/S3II Gps Surveying Instruments GNSS Rover And Base Station RTK

All Category

International Version STONEX S700A/S3II Gps Surveying Instruments GNSS Rover And Base Station RTK

Brand Name:	STONEX
Model Number:	S700A/S3II
MOQ:	1 piece
Price:	$3,100.00
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Brand Name:

STONEX

Model Number:

S700A/S3II

Product Name:

RTK Receiver STONEX S700A/S3II

Customized Support:

OEM

Channel:

800 Channels

Transmitting Power:

0.5W, 1W, 2W Adjustable

Transmitting Speed:

9.6Kbps, 19.2Kbps

Gps:

L1 ,L2, L5

Working Range:

5km Typical, 8~10km Optimal

BDS:

B1, B2, B3

Minimum Order Quantity:

1 piece

Price:

$3,100.00

Delivery Time:

30 work day

Payment Terms:

L/C, T/T

Supply Ability:

1 ~ 30 day

Highlight:

stonex rtk gnss

stonex gnss rtk receiver

gps rtk gnss

Product Description

International Version STONEX S700A/S3II Gps Surveying Instruments GNSS Rover And Base Station RTK

FAQ

Model	S3ll
Satellite system
Satellite system	BeiDou/GPS/GLONASS/Galileo,ATLAS
Tracking
channel	800channels
GPS	L1 ,L2, L5
GLONASS	G1 C/P, G2C, G2P, G3
BDS	B1, B2, B3
Galileo	E1, E5a, E5b
Aided positioning	IRNSS L5
	SBAS L1, L5
	QZSS L1 C/A, L1C, L2C, L5, L6
L-BAND	TerraStar(optional)
L-BAND	RTK ASSIST(optional)
Performace Index
Static H Accuracy	±(2.5mm+1ppm)RMS
Static V Accuracy	±(5mm+1ppm)RMS
RTK measure H Accuracy	±(8mm+1ppm)RMS
RTK measure V Accuracy	±(15mm+1ppm)RMS
ATLASposition*	H:5cm
ATLASposition*	V:10cm
Initialization time	<10s
Initialization reliability	>99.99%
Data Output Rate	1Hz-20Hz
Static Storage and Data Output
Storage format	Dat/Rinex
Storage memory	Standard 16G
Storage way	Two formats of data can be stored at the same time
Download way	Suooprt USBdownloada &Web download
Export format	NMEA0183,PJKPlanar coordinates, binary codes
Export way	blue tooth/WIFI/RS 232/radio/network

blue tooth	2.1/4.1 LE dual Modular
WiFi	802.11 b/g/n
voice	Support voice broadcasting
Communication protocol	TrimTalk / TrimMask 3;PCC EOT;Geotalk;Hi-target
Radio	Built-in transceiver:0.5W/1W(can adjust)
	external launch:5W/35W(can adjust)
	working frequency:410-470MHz
I/O port	1 LEMO data port,USB data download,U disk upgrade function
	1 LEMO port,External Output Input,External power supply
	1 LEMO power port;1 TNC radio port
Difference scheme	RTCM2.X,RTCM3.X,CMR,CMR+,ROX
GNSS Antenna characteristics
GNSSAntenna characteristics	Integrated built-in antenna with zero phase center difference
environment
working temperature	-30ºC~+70ºC
Storage temperature	-40ºC~+80ºC
Waterproof and dust-proof	IP67
Fall prevention	Resistance to 2 m drop with pole (hard ground with concrete)
Water proof	Immersion 1 m underwater (30 minutes)
humidity	100% condensation resistance
Physical and power characteristics
Using time	>10 hours
size	146mm×146mm× 76mm
weight	1.2kg
battery	7.2V 6800mAh
key	1 key

Model	S3ll
Satellite system
Satellite system	BeiDou/GPS/GLONASS/Galileo,ATLAS
Tracking
channel	800channels
GPS	L1 ,L2, L5
GLONASS	G1 C/P, G2C, G2P, G3
BDS	B1, B2, B3
Galileo	E1, E5a, E5b
Aided positioning	IRNSS L5
	SBAS L1, L5
	QZSS L1 C/A, L1C, L2C, L5, L6
L-BAND	TerraStar(optional)
L-BAND	RTK ASSIST(optional)
Performace Index
Static H Accuracy	±(2.5mm+1ppm)RMS
Static V Accuracy	±(5mm+1ppm)RMS
RTK measure H Accuracy	±(8mm+1ppm)RMS
RTK measure V Accuracy	±(15mm+1ppm)RMS
ATLASposition*	H:5cm
ATLASposition*	V:10cm
Initialization time	<10s
Initialization reliability	>99.99%
Data Output Rate	1Hz-20Hz
Static Storage and Data Output
Storage format	Dat/Rinex
Storage memory	Standard 16G
Storage way	Two formats of data can be stored at the same time
Download way	Suooprt USBdownloada &Web download
Export format	NMEA0183,PJKPlanar coordinates, binary codes
Export way	blue tooth/WIFI/RS 232/radio/network

blue tooth	2.1/4.1 LE dual Modular
WiFi	802.11 b/g/n
voice	Support voice broadcasting
Communication protocol	TrimTalk / TrimMask 3;PCC EOT;Geotalk;Hi-target
Radio	Built-in transceiver:0.5W/1W(can adjust)
	external launch:5W/35W(can adjust)
	working frequency:410-470MHz
I/O port	1 LEMO data port,USB data download,U disk upgrade function
	1 LEMO port,External Output Input,External power supply
	1 LEMO power port;1 TNC radio port
Difference scheme	RTCM2.X,RTCM3.X,CMR,CMR+,ROX
GNSS Antenna characteristics
GNSSAntenna characteristics	Integrated built-in antenna with zero phase center difference
environment
working temperature	-30ºC~+70ºC
Storage temperature	-40ºC~+80ºC
Waterproof and dust-proof	IP67
Fall prevention	Resistance to 2 m drop with pole (hard ground with concrete)
Water proof	Immersion 1 m underwater (30 minutes)
humidity	100% condensation resistance
Physical and power characteristics
Using time	>10 hours
size	146mm×146mm× 76mm
weight	1.2kg
battery	7.2V 6800mAh
key	1 key
