1598 channels Kolida K1 Pro Gps Base and Rover RTK Surveying Equipment High Accuracy Gps Receiver

Brand Name:	Kolida
Model Number:	K1 Pro
MOQ:	1 piece
Price:	$2,700.00
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

RTK Receiver Kolida K1 Pro

Customized Support:

OEM, ODM, OBM

Material:

Aluminum Alloy

Color:

Red And Gray

Power:

Li-ion Battery

Channels:

L1C/A,L2P,L2C,L5,L1C*

Internal Radio:

Transmitting And Receiving

Supply Ability:

1 ~ 30 day

Highlight:

rtk base rover gps

rtk gps base and rover

receiver base rover gps

Product Description

1598 channels Kolida K1 Pro Gps Base and Rover RTK Surveying Equipment High Accuracy Gps Receiver

Overview

Products Descriptin

Data Collector

Technical Parameters

Configuration	Detailed indicators
Signal tracking	BDS-2:B1I,B2I,B3I, BDS-3:B1I,B3I,B1C,B2a,B2b GPS: L1C/A,L2P,L2C,L5,L1C* GLONASS:G1,G2,G3* SBAS:L1L1C/A,L5* Galileo: E1,E5b,E5a,E5 AltBoc,E6c QZSS:L1,L2C,L5 IRNSS:L5* 1598 channels
GNSS characteristics	Positioning output frequency 1Hz~50Hz The initialization time is less than 10 seconds Initialization reliability>99.99% All constellation reception technology, capable of supporting GNSS constellation signals from all current and planned sources High reliability carrier tracking technology improves carrier accuracy and provides high-quality raw observation data Intelligent dynamic sensitivity positioning technology, adaptable to various environmental changes and harsh, long-distance positioning environments High precision positioning processing engine
Code differential GNSS positioning	Horizontal: 0.25 m+1 ppm RMS Vertical: 0.50 m+1 ppm RMS SBAS differential positioning accuracy: typical
Static measurement accuracy	Horizontal: ± (2.5+0.5 × 10-6 × D) mm Elevation: ± (5.0+0.5 × 10-6 × D) mm
RTK measurement accuracy	Horizontal: ± (8+1 × 10-6 × D) mm Elevation: ± (15+1 × 10-6 × D) mm (D is the measured baseline length)
Operating System/Starlink	Linux/Starlink (optional): Within 4CM, convergence time less than 30min; MSSL Band
Button/LCD screen	Double key operation, convenient and fast/high-definition 0.96 inch OLED screen, resolution 128 x 64
Indicator light	Five indicator lights
Web interaction	Built in Web UI management backend, supporting WiFi and USB mode access to the receiver's built-in Web UI management page, real-time monitoring of host status, and free configuration of hosts.
Voice	IVoice intelligent voice technology, intelligent status reporting, voice operation prompts; Chinese, English, Korean, Russian, Portuguese, Spanish and Turkish are supported by default; Support voice customization
Secondary development	Provide a secondary development package, open OpenSIC observation data format, and define interaction interfaces for secondary development
Data cloud services	Web version cloud service management platform, supporting remote management and data exchange services such as online registration
Size	163x163x96mm
Weight	1.33Kg
Material	Magnesium alloy
Temperature	Working temperature: -25 ° C to+65 ° C Storage temperature: -40 ° C to+80 ° C
Humidity	Anti 100% condensation
Protection level	Waterproof: 1m immersion, IP68 level Dust prevention: completely prevents dust from entering, IP68 level
Shockproof	Resistance to 2 meters of pole drop
Power supply	9-28V wide voltage DC design with overvoltage protection
Battery	High capacity built-in battery 10000mAh 7.4V
Power solution	Regular homework meets a 14 hour battery life, supports pole shaped battery rod power supply, and can support other variable voltage power supply systems (providing a 7 * 24-hour continuous working power supply solution)
I/O ports	5PIN LEMO external power interface+RS232 7PIN LEMO external USB (OTG) 1 radio data link antenna interface SIM card slot (medium card)
Radio modem	Equipped with a high-power integrated transceiver radio, with a typical operating distance of 15km and a working frequency of 410-470MHz, Supports external transmitting radio 5W/25W/35W, can switch network routing, radio relay mode, communication protocols: SOUTH, TrimTalk, Satellite, ZHD, HUACE
Bluetooth	BLEBluetooth 4.0 Bluetooth standard, supporting Android system phone connection; Bluetooth 2.1+EDR standard
NFC wireless communication	Using NFC wireless communication technology, the manual can automatically pair with the host by touching it (the manual also needs to be equipped with NFC wireless communication module)
Cellular mobility	Intelligent PPP dialing technology based on Linux platform, automatic real-time dialing, continuous online during operation, equipped with 4G all network high-speed network communication module, compatible with various CORS System access. The host is equipped with a built-in network antenna, making homework easier. Adopting eSIM card technology, embedded with eSIM chip, no need to insert a card, providing real-time network resources to ensure the host Online homework continuous online (optional)
WIFI standard	802.11b/g/n standard
WIFI hotspot	Equipped with WIFI hotspot function, any intelligent terminal can access the receiver, providing rich personalized customization of receiver functions; Industrial notebooks, intelligent terminals, and other data collectors can transmit data to the receiver via WIFI
WIFI data link	The receiver can be connected to WIFI for differential data broadcasting or reception
Data storage	8G built-in solid-state memory, supporting 32G external expansion; Automatic cyclic storage (automatically deleting the earliest data when storage space is insufficient); Supports external USB storage for Data storage; Rich sampling intervals, supporting up to 50Hz raw observation data collection
Data transmission	One click intelligent copying directly exports static data from the host through external USB storage; Plug and play USB data transmission method; FTP download, HTTP download
Data format	Static data formats: multiple formats such as STH, Rinex2.01, and Rinex3.02 Differential data formats: CMR+, CMRx, RTCM 2.1, RTCM 2.3, RTCM 3.0, RTCM 3.1, RTCM 3.2 Input and Output Input and output; GPS output data format: NMEA 0183, PJK plane coordinates, binary code, Trimble GSOF;
Inertial tilt measurement	Built in IMU inertial measurement sensor, supporting inertial tilt measurement function, automatically correcting coordinates based on the tilt direction and angle of the center pole.
Electron bubble	Equipped with a built-in sensor, the manual software can display electronic bubbles and check the leveling of the center pole in real-time
Temperature sensor Shake and tilt measurement	Built in temperature sensor, using intelligent variable frequency temperature control technology, real-time monitoring and adjustment of host temperature Core patented algorithm that automatically corrects coordinates based on the tilt direction and angle of the center pole by swinging the host
