GNSS RTK Receiver

824 channels CHCNAV E91 Base and Rover Visual RTK Surveying Equipment High Accuracy Gps Receiver

All Category

Echo Sounder

Miss. Lili Zhou

yyi658731@gmail.com

ChengDu-3987

Contact Now

824 channels CHCNAV E91 Base and Rover Visual RTK Surveying Equipment High Accuracy Gps Receiver

Brand Name:	CHCNAV
Model Number:	E91
MOQ:	1 piece
Price:	$2,800.00
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

GNSS RTK Receiver CHCNAVE91

Customized Support:

OEM, ODM, OBM

Application:

Land Surveying

Function:

GPS RTK Survey (Radio

Material:

Magnessium Alloy

Channels:

824

Weight:

0.77kg

Wate Proof:

IP67

Supply Ability:

1 ~ 30 day

Highlight:

chcnav rtk gnss

chcnav gnss rtk receiver

gps rtk gnss

Product Description

824 channels CHCNAV E91 Base and Rover Visual RTK Surveying Equipment High Accuracy Gps Receiver

Overview

Products Descriptin

High Accuracy GPS Receiver 624 channels CHC E91 gnss rtk with multiple radio protocol
Gnss	Channel	624
	Satellite Tracked	GPS L1CA/L1P/L1C/L2P/L2C/L5
		GLONASS G1, G2, G3
		Galileo E1, E5a, E5b, ALTBOC, E6
		QZSS L1, L2 L5,
		BeiDou B1I, B2I, B3I, B1C, B2a, B2b, ACEBOC
		SBAS Ll, L5
Performance	Update rate	5 Hz, up to 50 Hz
	Signal Reacquisition	< 1 sec
	Hot Start	< 10 sec
	Initialization Reliability	> 99.9%
	Memory	8 GB
Real-Time Accuracy (rms)	Static Accuracy	Horizontal:3mm + 1ppm
	Static Accuracy	Vertical:5 mm + 1 ppm
	RTK Accuracy	Horizontal:8 mm + 1 ppm
	RTK Accuracy	Vertical:15 mm + 1 ppm
	Code Differential	Horizontal:0.4 m
	SBAS Accuracy	Horizontal:0.8 m
Communication	7-pin	Connect to external power and radio
	USB	For charging and data transmission
	Cellular	Global 4G
	Bluetooth	V4.1
	WIFI	802.11 ac/n/b/g/n
	WebUI	Update firmware, manage settings and
	WebUI	status, download data
	Date formats	CNR input and out put
		RTCM 2.x, RTCM 3.x input and output
		NMEA 0183 output
		HCN, HRC and RINEX 2.11, RINEX 3.02
		NTRIP Client, NTRIP Caster
	Electronic Bubble	Support
	Dimensions	16015896mm , 1.55KG
	Shock	Survive a 2 m pole drop on concrete floor 1.2 m free drop
	5-pin lemo port	connecting external power supply and external radio
	SIM Card	NANO SIM
	Cellular	Global 4G
	Bluetooth	V2.1+EDR / V4.1 Dual Mode, Class 2
	WIFI	802.11 ac/n/b/g/n
	WebUI	Update firmware, manage settings and
	WebUI	status, download data
	Electronic Bubble	Support
Environment	Dustproof&Waterproof	IP67 (Customizable IP68)
Environment	Humidity	95% non-condense
Power Supply	Battery	Rechargeable, built-in Lithium-ion battery,7.2 V - 10200 mAh
	Voltage	9~28 V DC external power input
	Working Time	Up to 16 hours
	Charge Time	Typically 4 hours
Internal Radio	Frequency Range	410 - 470 MHz
	Protocol	CHC, Transparent, TT450
	Emitting Power	0.5 W / 2 W
	Operating Range	5 km typically

Why Choose Us

GEODETSKOJ ŠKOLI SPLIT isporučujemo STONEX totalne stanice, teodolite i GNSS prijemnike

Geodetske škole imaju ključnu ulogu u pružanju učenicima potrebnog znanja i vještina u području geodezije.Integracija najnovijih
geodetskih instrumenata u takve obrazovne ustanové može značajno poboljšati iskustvo učenika i bolje ih pripremiti za primjenu u
stvarnom svijetu.Najnoviji geodetski instrumenti nude napredne značajke i mogućnosti koje mogu pružiti studentima intenzivnije
iskustvo učenja.Korištenjem ovih instrumenata, studenti mogu steći praktično iskustvo u prikupljanju podataka, analizi itumačenju, što su ključne vještine u području geodezije.
U suradnji sa STONEX S.r.l. Italija, geodetskoj školi u Splitu isporučili smo najnovije totalne stanice, teodolite i GNSS prijemnike.

Customer Photos

Certifications

Company Profile

FAQ

1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),North America(4.00%),Eastern
Europe(4.00%). There are total about 11-20 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
