GPS Receiver For A Novice SANDING T9 Base And Rover RTK Surveying Equipment

Brand Name:	SANDING
Model Number:	T9
MOQ:	1 piece
Price:	$3,500.00
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

GNSS RTK Receiver SANDING T9

Customized Support:

OEM, ODM, OBM

Application:

Land Surveying

Function:

GPS RTK Survey (Radio

Material:

Magnessium Alloy

Channels:

1598

GLONASS:

L1C/A, L1P, L2C/A, L2P, L3

Voice:

Multi-language Switching

Supply Ability:

1 ~ 30 day

Highlight:

gps rtk gnss

gps gnss rtk receiver

receiver rtk gnss

Product Description

GPS Receiver For A Novice SANDING T9 Base And Rover RTK Surveying Equipment

Overview

Products Descriptin

GNSSconfiguration	Number of channels	1598 channels
	BDS	BDS-2: B1I, B2I, B3I BDS-3: B1I, B3I, B1C, B2a, B2b
	GPS	L1,L1C,L2C,L2P,L5
	GLONASS	L1C/A,L1P,L2C/A,L2P,L3
	GALILEO	GIOVE-A,GIOVE-B,E1,E5A,E5B
	QZSS	L1C/A,L1 SAiF ,L2C,L5
	Positioning output rate	1Hz~20Hz
	Differential support	CMR,RTCM2.X,RTCM3.0,RTCM3.2
	Static format support	GNS, Rinex dual format static data
	RTK positioning accuracy	Plane: ±(8+1×10-6D) mm (D is the distance between the measured points) Elevation: ±(15+1×10-6D) mm (D is the distance between the measured points)
	Static positioning accuracy	Plane: ±(2.5+0.5×10¯6D) mm (D is the distance between the measured points) Elevation: ±(5+0.5×10¯6D) mm (D is the distance between the measured points)
	DGPS positioning accuracy	Plane accuracy: ±0.25m+1ppm;Elevation accuracy: ±0.50m+1ppm
	Initialization time	<10 seconds
	Initialization reliability	＞99.99%
	IMU tilt compensation	Additional horizontal pole tip uncertainty typically less than 10mm + 0.7 mm/° tilt down to 30° IMU tilt angle:0°~60°
communication	NFC Communication	Realizing close range (shorter than 10cm) automatic pair between receiver and controller (controller equipped NFC wireless communication module needed)
	WiFi	802.11b/g access point and client mode, can provide WiFi hotspot service
	Bluetooth	BLEBluetooth 4.0 standard, support for android, ios cellphone connection
	Wireless modem	Built-in radio, 1W/2W/3W switchable, typically work range can be 8KM Radio repeater
	I/O port	5PIN LEMO external power port + RS232, 7PIN external USB(OTG)+Ethernet 1 radio antenna interface
	frequency band:	410-470MHz
	Protocol	Farlink, Trim talk450s, SOUTH, HU ACE, Hi-tar get, Sa tel
User Interface	Buttons	One button operation
User Interface	Indicators	Four indicate lights
Electrical physical properties	battery	10000mAh, 7.4V
	Power Supply	9-28V DC, over voltag e protecon
	size	166mm x 96.1mm
	weight	1.3KG
	material	Magnesium aluminum alloy shell
Environmental characteristics	Dust and water release	IP67 standard, protected from long time immersion to depth of 1m
	Storag	-55°C~+85°C
	Operating	-45℃~70℃
Specification
System	model	H6
	operating system	Android 8.1
	CPU	Octa-core 2.0GHz
	RAM	4GB
	ROM	64GB
Communication	SIM frequencies	GSM: B2/B3/B5/B8 FDD-LTE :B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B20/B25/B28 TDD-LTE B38/B39/B40/B41 TDSCDMA B34/B39 WCDMA B1/B2/B5/B8 CDMA1x/CDMA2000 BC0
	WiFi(WLAN)	IEEE 802.11a/b/g/n, 2.4G/5G
	Bluetooth	V4.1
	NFC	Support NFC IGRS
	USB	Type-C, support OTG
Electrical	Battery	9200mAh
	Operating Time	15 Hrs
	Charging Time	240 Hrs
Physical	size	235mm90mm35mm
	Weight	520g
	Operating temperature	-20℃~+60℃

Products Description

If you have any questions, please consult customer service

Why Choose Us

GEODETSKOJ ŠKOLI SPLIT isporučujemo STONEX totalne stanice, teodolite i GNSS prijemnike

Geodetske škole imaju ključnu ulogu u pružanju učenicima potrebnog znanja i vještina u području geodezije.Integracija najnovijih
geodetskih instrumenata u takve obrazovne ustanové može značajno poboljšati iskustvo učenika i bolje ih pripremiti za primjenu u
stvarnom svijetu.Najnoviji geodetski instrumenti nude napredne značajke i mogućnosti koje mogu pružiti studentima intenzivnije
iskustvo učenja.Korištenjem ovih instrumenata, studenti mogu steći praktično iskustvo u prikupljanju podataka, analizi itumačenju, što su ključne vještine u području geodezije.
U suradnji sa STONEX S.r.l. Italija, geodetskoj školi u Splitu isporučili smo najnovije totalne stanice, teodolite i GNSS prijemnike.

Certifications

Company Profile

FAQ

1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),North America(4.00%),Eastern
Europe(4.00%). There are total about 11-20 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian

Our Service

Packing & Delivery
