GNSS RTK Receiver

GNSS RTK Hi -Target IRTK120 Upgrade For Land Surveying Instruments Survey IMU GPS

All Category

Echo Sounder

Miss. Lili Zhou

yyi658731@gmail.com

ChengDu-3987

Contact Now

GNSS RTK Hi -Target IRTK120 Upgrade For Land Surveying Instruments Survey IMU GPS

Brand Name:	Hi-target
Model Number:	iRTK20
MOQ:	1 piece
Price:	$2,200.00
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

RTK Receiver Hi-target IRTK20

Material:

Magnesium Alloy

Application:

Land Surveying

Frequency:

1Hz~20Hz

Working Range:

5km Typical, 8~10km Optimal

Weight:

0.75kg

Internal Battery Life:

Static 16hours

Supports:

Supply Ability:

1 ~ 30 day

Highlight:

imu rtk gnss

imu gnss rtk receiver

gps rtk gnss

Product Description

GNSS RTK Hi -Target IRTK120 Upgrade For Land Surveying Instruments Survey IMU GPS

Products Description

RTK IRTK20 technical parameters
GNSS configuration	Number of channels: 1408
	BDS: B1I, B2I, B3I, B1C, B2a, B2b
	GPS: L1C/A, L1C, L2P(Y), L2C, L5
	GLONASS: L1, L2
	GALILIEO: E1, E5a, E5b, E6
	SBAS: Support
	QZSS: Support
	Output format	ASCII: NMEA-0183, binary code
	Positioning output frequency	1Hz~20Hz
	Static data format	GNS, Rinex dual format static data
	Difference format	CMR, RTCM2.X, RTCM3.0, RTCM3.2
	Network mode	VRS, FKP, MAC; support NTRIP protocol
System Configuration	operating system	Linux operating system
	Start Time	3 seconds
	data storage	Built-in 8GB ROM, supports automatic storage of static data
Accuracy and reliability [1]	RTK positioning accuracy	Plane: ±(8+1×10-6D) mm (D is the distance between the measured points)
		Elevation: ±(15+1×10-6D) mm (D is the distance between the measured points)
	Static positioning accuracy	Plane: ±(2.5+0.5×10-6D) mm (D is the distance between the measured points)
		Elevation: ±(5+0.5×10-6D) mm (D is the distance between the measured points)
	DGPS positioning accuracy	Plane accuracy: ±0.25m+1ppm; elevation accuracy: ±0.50m+1ppm
	SBAS positioning accuracy	0.5m
	Initialization time	<10 seconds
	Initialization reliability	>99.99%
Communication unit	I/O port	USB Type-C interface, SMA interface
	Built-in 4G network communication	Built-in eSIM4 card, including 3 years Internet access fee, you can connect to the Internet after power on
	WiFi communication	802.11 a/b/g/n access point and client mode, can provide WiFi hotspot service
	blue tooth communication	blue tooth® 4.2/2.1+EDR, 2.4GHz
	Built-in radio	Built-in transceiver station:
		Power: 0.5W/1W/2W adjustable
		Frequency band: 410MHz~470MHz
		Protocol: HI-TARGET, TRIMTALK450S, TRIMMARKⅢ, TRANSEOT
		Number of channels: 116 (16 of which can be configured)
sensor	Electronic bubble	Realize smart alignment
	Tilt measurement	Built-in high-precision inertial navigation, automatic attitude compensation, 8mm+0.7mm/°tilt (accuracy within 30°<2.5cm)
User Interface	button	A power button
	LED indicator light	Satellite lights, signal lights, power lights
	WEB UI	Built-in WEB page to realize receiver setting and status check
Function application	Advanced Features	OTG function, NFC IGRS, WebUI interaction, U disk firmware upgrade
	Smart application	Smart base station, smart voice, function self-check, smart CORS
	Remote Service	News push, online upgrade, remote control
	cloud service	Equipment management, location services, collaborative operations, data analysis
Physical characteristics	Host battery	Built-in high-capacity lithium battery 6800mAh/7.4V, network mobile station working time is more than 10 hours[2]
	External power supply	Support USB port charging and external power supply
	size	Φ130mmx79mm
	weight	≤0.75kg
	Power consumption	4.2W
	material	The shell is made of magnesium alloy material
Environmental characteristics	Dustproof and waterproof	IP68
	Anti-fall	Resistance to natural drop of 2m high measuring rod
	Relative humidity	100% non-condensing
	Operating temperature	-45℃~+75℃
	storage temperature	-55℃~+85℃

Details Images

Why Choose Us

GEODETSKOJ ŠKOLI SPLIT isporučujemo STONEX totalne stanice, teodolite i GNSS prijemnike

Geodetske škole imaju ključnu ulogu u pružanju učenicima potrebnog znanja i vještina u području geodezije.Integracija najnovijih
geodetskih instrumenata u takve obrazovne ustanové može značajno poboljšati iskustvo učenika i bolje ih pripremiti za primjenu u
stvarnom svijetu.Najnoviji geodetski instrumenti nude napredne značajke i mogućnosti koje mogu pružiti studentima intenzivnije
iskustvo učenja.Korištenjem ovih instrumenata, studenti mogu steći praktično iskustvo u prikupljanju podataka, analizi itumačenju, što su ključne vještine u području geodezije.
U suradnji sa STONEX S.r.l. Italija, geodetskoj školi u Splitu isporučili smo najnovije totalne stanice, teodolite i GNSS prijemnike.

Certifications

Company Profile

FAQ

1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),North America(4.00%),Eastern
Europe(4.00%). There are total about 11-20 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian

Our Service

Packing & Delivery
