GPS GNSS RTK Hi -target TS2 Base and Rover upgrade for land surveying instruments

Brand Name:	Hi-target
Model Number:	TS2
MOQ:	1 piece
Price:	$2,300.00
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

RTK Receiver Hi-target TS2

Material:

Magnesium Alloy

Application:

Land Surveying

Channels:

1408

Customized Support:

OEM

GPS:

L1C/A,L1C,L2P(Y),L2C,L5

BDS:

B1I,B2I,B3I,B1C,B2a,B2b

Weight:

1.5kg

Supply Ability:

1 ~ 30 day

Highlight:

land surveying gps gnss rtk

land surveying rtk gps gnss

l2p gps gnss rtk

Product Description

GPS GNSS RTK Hi -target TS2 Base and Rover upgrade for land surveying instruments

Products Description

Technical Parameters

SS configuration	Channel: 1408
	Satellite tracking:BDS:B1I,B2I,B3I,B1C,B2a,B2b
	GPS:L1C/A,L1C,L2P(Y),L2C,L5
	GLONASS:L1,L2
	GALILEO:E1,E5a,E5b,E6*
	QZSS:L1,L2,L5,L6*
	IRNSS:L5*
	SBAS:L1,L2,L5
	L-BAND*
	Output format	ASCII:NMEA-0183,Binary code
	Positioning output frequency	1Hz~20Hz
	Static data format	GNS, Rinex dual-format static data
	Difference scheme	RTCM2.X,RTCM3.X
	Network mode	VRS,FKP,MAC; Supports the NTRIP protocol
System configuration	Operating system	Linux Operating system
	Data storage	Built-in 16GB ROM, support static data automatic cycle storage
Accuracy and reliability	RTK positioning accuracy	Plane: ±(8+1×10-6Dmm(D is the distance between measured points)
		Height: ±(15+1×10-6D)mm(D is the distance between measured points)
	Static positioning accuracy	Plane: ±(2.5+0.5×10-6D)mm(D is the distance between measured points)
		Height: ±(5+0.5×10-6D)mm(D is the distance between measured points)
	Difference accuracy of satellite station	Plane accuracy: 10cm; Height accuracy: 20cm
	DGPS positioning accuracy	Plane accuracy: ±0.25m+1ppm; Elevation accuracy: ±0.50m+1ppm
	SBAS positioning accuracy	0.5m
	Inclination measurement accuracy	8mm+0.7mm/°tilt
	Image lofting accuracy	1cm
	Initialization time	<10 seconds
	Initialization reliability	>99.99%
	Breakpoint continuation	RTK measurements are still available during differential signal outages
Camera	function	Professional star night vision HD camera, large viewing Angle, support real scene lofting
Communication unit	I/0 port	USB Type-C port, SMA port
	Cellular mobility	eSIM card: Support host and manual double eSIM, double network double standby, including 3 years of traffic, boot is high precision
		Built-in 4G network communication: TDD-LTE,FDD-LTE,WCDMA,TD-SCDMA,EDGE,GPRS,GSM
	WiFi communication	802.11a /b/g/n access point and client mode to provide WiFi hotspot services
	Bluetooth communication	Bluetooth® 2.4GHz, BT5.2
	Built-in full protocol radio	Transceiver integration: base station transmission and mobile station reception
		Power: 0.5W/1W/2W adjustable
		Frequency band: 410MHz to 470MHz
		Protocol: HI-TARGET,TRIMTALK450S,TRIMMARKⅢ,TRANSEOT,SOUTH,CHC,SATEL
		Number of channels: 116(16 of which are configurable)
Sensor	Electronic bubbles: Intelligent alignment
	Tilt measurement: Built-in a new generation of high-precision inertial navigation, automatic startup initialization, automatic attitude compensation
User interface	Button: Single button
	LED prompt light: satellite light, signal light, power light
Functional application	Advanced functions: NFC flash link, WebUI interaction, USB flash drive firmware upgrade
	Intelligent application: intelligent voice, function self-test
	Remote service: message push, online upgrade, remote control
	Cloud services: Device management, location services, collaborative work, data analytics
Physical characteristics	Host battery: high capacity lithium battery 6800mAh, working time is better than 16 hours
	External power supply: USB 15W charging
	Size: Φ130mm×68mm
Environmental characteristics	Dustproof and waterproof: IP68
	Anti-fall: Resist the natural fall of 2 meters high measuring pole
	Relative humidity: 100% non-condensing
	Operating temperature: -45℃~+75℃
	Storage temperature: -55℃~+85℃
