GNSS RTK Hi -target A31 Base and Rover upgrade for land surveying instruments

Brand Name:	Hi-target
Model Number:	A31
MOQ:	1 piece
Price:	$2,500.00
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

RTK Receiver Hi-target A31

Material:

Magnesium Alloy

Application:

Land Surveying

Channels:

1408

Customized Support:

OEM

Operating Temperature:

-45℃~+75℃

Storage Temperature:

-55℃~+85℃

Weight:

0.68kg

Supply Ability:

1 ~ 30 day

Highlight:

land surveying rtk gnss

land surveying gnss rtk receiver

oem rtk gnss

Product Description

GNSS RTK Hi -target A31 Base and Rover upgrade for land surveying instruments

Products Description

GNSS configuration	Number of channels:	1408
	Satellite tracking	BDS:B1I,B2I,B3I,B1C,B2a,B2b
		GPS:L1C/A,L1C,L2P(Y),L2C,L5
		GLONASS:L1,L2
		GALILEO:E1,E5a,E5b,E6*
		QZSS:L1,L2,L5,L6*
		IRNSS:L5*
		SBAS:L1,L2,L5
		L-BAND*
	Output format:	ASCII: NMEA-0183, binary code
	Positioning output frequency	1Hz~20Hz
	Static data format	GNS, Rinex dual-format static data
	Difference scheme	RTCM2.X,RTCM3.X
	Network mode	VRS, FKP, MAC; Supports the NTRIP protocol
System configuration	Operating system	Linux operating system
System configuration	Data storage	Built-in 8GB ROM, support static data automatic cyclic storage
Accuracy and reliability	RTK positioning accuracy	Plane: ± (8+1×10-6D) mm (D is the distance between measured points)
	RTK positioning accuracy	Elevation: ± (15+1×10-6D) mm (D is the distance between measured points)
	Static positioning accuracy	Plane: ± (2.5+0.5×10-6D) mm (D is the distance between measured points)
	Static positioning accuracy	Elevation: ± (5+0.5×10-6D) mm (D is the distance between measured points)
	Difference accuracy of satellite station	Plane accuracy: 10cm; Height accuracy: 20cm
	DGPS positioning accuracy	Plane accuracy: ±0.25m+1ppm; Elevation accuracy: ±0.50m+1ppm
	Positioning accuracy of SBAS	0.5m
	Inclination measurement accuracy	8mm+0.7mm/°tilt
	Image lofting accuracy	1cm
	Initialization time	< 10 seconds
	Initialization reliability	＞99.99%
	Breakpoint continuation	RTK measurements are still provided during differential signal outages
Camera	Function	Professional star night vision HD camera, large Angle of view, support real scene lofting
Communication unit	I/O port	USB type C interface; SMA interface
	WiFi communication	802.11a /b/g/n access point and client mode to provide WiFi hotspot services
	Bluetooth communication	Bluetooth® 2.4GHz, BT5.2
	Built-in full protocol radio	Frequency band: 410MHz to 470MHz
		Power: 0.5W/1W/2W adjustable
		Transceiver integrated: base station transmission and mobile station reception
		Protocol: HI-TARGET, TRIMTALK450S, TRIMMARKⅢ,TRANSEOT,SOUTH,CHC,SATEL
		Number of channels: 116 channels (16 of which are configurable)
Sensor	Electron bubble	Realize intelligent alignment
Sensor	Tilt measurement	Built-in new high precision inertial navigation, boot automatic initialization, automatic attitude compensation
User interface	Button	Single Button
User interface	LED cue light	Satellite lights, signal lights, power lights
Functional application	Advanced function	Flash link of NFC, WebUI interaction, USB flash drive firmware upgrade
	Intelligent application	Intelligent voice, function self-check
	Remote service	Message push, online upgrade, remote control
	Cloud service	Equipment management, location services, collaborative work, data analysis
Physical characteristics	Main engine battery	High capacity and high performance lithium battery, working time is better than 24 hours
	External power supply	USB 15W charging
	Dimension	Φ130mm×73mm
	Weight	≤0.68kg
	Material	The shell is made of magnesium alloy
	Dustproof and waterproof	IP68
	anti-fall	Resist natural drop of 2 meter high measuring rod
	Relative humidity	100% non-condensing
	Operating temperature	-45℃~+75℃
	Storage temperature	-55℃~+85℃
