RUIDE Land Survey Robotic Total Station Instrument No Prism

Brand Name:	Ruide
Model Number:	RTS-822R10X
MOQ:	1 set
Price:	＄1,500.00
Payment Terms:	T/T, L/C

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

Robotic Total Station

Customized Support:

OEM, ODM, OBM

Brand Name:

Ruide

Model:

Magnification:

Reflectorless:

1000m

Single Prism:

5000m

Display:

LCD Display

Accuracy: Non Prism:

2+2ppm

Accuracy:

Angle Measurement:

Absolute Encoding Angle Measurement

Operating Time:

15 Hour

Waterproof And Dustproof:

Highlight:

RUIDE survey robotic total station

Land survey robotic total station

RUIDE total station instrument

Product Description

RUIDE RQS/RTS-822R10X total station no-prism 1000m and 2'' accuracy for land surveying

Specification

Ruide Total Station
Model	RQS
TELESCOPE
Length	154mm
Objective Lens Diameter	Telescope:45mm Distance Meter: 50mm
Magnification	30X
Image	Erect
Field of View	1°30’
Resolving Power	3"
Min. Focus	1.0m
DISTANCE MEASUREMENT
Single Prism	5000m*1
Non-prism	600m*2
Accury -Prism Mode	±(2mm+2ppm x D) m.s.e*3
-Non-prism Mode	±(3mm+2ppm x D) m.s.e*3
Measuring Time	Fine:0.6s,Normal: 0.5s
Meteorologic Correction	ATMOSense (Auto Sensing)
Prism Constant	Manuual Input
ANGLE MEASUREMENT
Method	Absolute Encoding
Detecting System	H: 2 sides,V:2 sides
Min. Reading	1"/5"
Accuracy	2"
Diamater of Circle	79mm
Vertical Angle 0°	Zenith 0°/ Horizontal: 0°
Unit	360°/400gon/6400mil
DISPLAY
Display Unit	Graphic LCD 160 x 90 Dots with White Backlight
No. of Unit	2 sides
Keyboard	Alphanumeric Key
TILT CORRECTION
Tilt Sensor	Dual Axis
Method	Liquid Electric
Range	±4'
Setting Unit	1″
LEVEL SENSITIVITY
Plate Level	30″/2mm
Circular Level	8'/2mm
OPTICAL PLUMMET (OPTIONAL:INTERNAL LASER PLUMMET)
Image	Erect
Magnification	3X
Focusing Range	0.3m~∞
Field of View	5°
DATA STORAGE & INTERFACE
Internal Memory	>10,000 points or >20,000 coordinates
Data Interface	RS 232/SD-card/Mini-USB
GENERAL
Guide Light	No
Weight & Dimension	5.4kg,340mm(H) x 160mm(W) x 150mm(L)
Working Temperature	-20℃~+50℃
Batter Type	Rechargeable Li-on Battery 3000mAh
Batter Voltage	DC 7.4V
Working Time	16h

RUIDE Land Survey Robotic Total Station Instrument No Prism 0
