Good price online

products details

Home > Products >
Robotic Total Station
>
IP55 Waterproof Mechanical Robotic Total Station 1000m Non Reflective
All Category

GNSS RTK Receiver

GIS Data Collector

Robotic Total Station

Electronic Theodolites

Laser Plummet

Automatic Level

Laser Distance Meters

3D Laser Scanner

UAV Drone Survey

Surpad 4.2 Software

Echo Sounder
Contact Us
Miss. Lili Zhou
yyi658731@gmail.com
wechat ChengDu-3987
Contact Now
IP55 Waterproof Mechanical Robotic Total Station 1000m Non Reflective
  • name
  • name
  • name
  • name
  • name
  • name
  • name

IP55 Waterproof Mechanical Robotic Total Station 1000m Non Reflective

Brand Name: Kolida
Model Number: 472R10L
MOQ: 1 set
Price: ＄2,200.00
Payment Terms: T/T, L/C
Detail Information
Product Description
Detail Information
Place of Origin:
China
Product Name:
Robotic Total Station
Customized Support:
OEM, ODM, OBM
Brand Name:
Kolida
Model:
472R10L
Magnification:
30X
Reflectorless:
1000m
Single Prism:
5000m
Display:
LCD Display
Accuracy: Non Prism:
2+2ppm
Accuracy:
2"
Angle Measurement:
Absolute Encoding Angle Measurement
Operating Time:
7 Hour
Waterproof And Dustproof:
IP55
Highlight:

IP55 Waterproof Robotic Total Station

,

Non Reflective Robotic Total Station

,

Waterproof mechanical total station

Product Description

Cheapest Price Kolida 472R10L Total Station 1000m Non Reflective Total Station





Specification

Adopt international advanced dual-axis compensation technology to automatically eliminate errors and compensate for them to improve accuracy

High-definition backlit display

Newly upgraded LCD display and font, large screen, large font backlighting, screen information can also be seen at a glance.

Built-in Bluetooth intelligent interaction

Built-in Bluetooth can communicate with the mobile terminal in real time, and seamlessly connect with the mobile phone surveyor software to achieve file upload and download, and through the transmission software can achieve data transfer with the PC terminal.

Abundant Measurement Procedures

The instrument has built-in rich measurement procedures to adapt to a variety of measurement projects through the optimisation of algorithms to improve the measurement accuracy of the instrument.



Models and technical parameters 472LL 472R4L 472R6L 472R8L 472R10L
Distance measurement With prism 5000m
Without prism   400m 600m 800m 1000m
Measurement Time Fine:0.3s, Tracking: 0.1s
Accuracy 2mm+2ppm(with prism), 3mm+2ppm(without prism)
Angle measurement Angle measurement mode Absolute angle encoder system
Minimum reading 0.1" /1" /5" Optional
Accuracy 2"
Telescope Image Erect
Magnification 30X
Objective aperture Telescope: 45mm, Distance Meter: 50mm
Field of view 1 30'
Minimum of focusing distance 1.0m
Resolution 3"
Compensation System Dual-Axis Liquid-Electric Sensor Compensation
Range 6'
Accuracy 1'
Level Plate level 30"/2mm
  Circular level 8'/2mm
Laser Plummet Accuracy 1.5mm (in 1.5m)
Laser spot Diameter 2.5mm (in 1.5m)
Display Type 2.8" LCD Color Screen 240*320dpi
Power Battery Rechargeable Li-ion battery
Voltage DC 7.4V
Continue Working Time 7 hours
Weight 5.2kg
Size 160*150*335mm



IP55 Waterproof Mechanical Robotic Total Station 1000m Non Reflective 0IP55 Waterproof Mechanical Robotic Total Station 1000m Non Reflective 1

IP55 Waterproof Mechanical Robotic Total Station 1000m Non Reflective 2IP55 Waterproof Mechanical Robotic Total Station 1000m Non Reflective 3





Certifications
IP55 Waterproof Mechanical Robotic Total Station 1000m Non Reflective 4
IP55 Waterproof Mechanical Robotic Total Station 1000m Non Reflective 5

Company Profile
IP55 Waterproof Mechanical Robotic Total Station 1000m Non Reflective 6


FAQ



1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),North America(4.00%),Eastern
Europe(4.00%). There are total about 11-20 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian



Our Service
IP55 Waterproof Mechanical Robotic Total Station 1000m Non Reflective 7

Packing & Delivery
IP55 Waterproof Mechanical Robotic Total Station 1000m Non Reflective 8
Tags:
