Kelida K90 Intelligent GNSS RTK Receiver GPS Drone Base Station For WebUI

Brand Name:	Kelida
Model Number:	K9
MOQ:	1 piece
Price:	$2,400.00
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

RTK Receiver

Material:

Magnesium Alloy

Operating Language:

English

Application:

Land Surveying

Channels:

1598 Channels

Weight:

1.06kg

GPS:

L1C/A,L2P,L2C,L5,L1C*

SBAS:

L1C/A,L5*

QZSS:

L1 、L2C、 L5

Glonass:

G1,G2,G3*

Galileos:

E1,E5b,E5a,E5 AltBoc*,E6c*

Protection Grade:

IP68

Supply Ability:

1 ~ 30 day

Highlight:

Kelida K90 GNSS RTK Receiver

WebUI GNSS RTK Receiver

l1 l2 gps receiver Base Station

Product Description

Cheap Kelida K90 intelligent gnss receiver 1598 channels gps gnss drone receiver base station rtk for WebUI

Product Description

Kolida's new K9 beyond version, with variable strain, strives to create a unique measurement operation, equipped with the latest generation of Beidou high-precision chips, supporting five stars and sixteen frequencies, and all constellation full frequency point calculation; Seamless connection for high-precision location services, with a unique radio antenna bracket design that enables 360 degree omnidirectional signal transmission, and an integrated built-in radio station with a typical operating distance of 10km.

Technical Parameters

Number of channels	1598
	BDS	B1I,B2I,B3I, B1I,B3I,B1C,B2a,B2b
	GPS	L1C/A,L2P,L2C,L5,L1C*
	GLONASS	G1,G2,G3*
	GALILEO	E1,E5b,E5a,E5 AltBoc,E6c
	QZSS	L1 ,L2C, L5/ IRNSS:L5/ SBAS:L1C/A,L5
	Positioning output rate	1Hz~20Hz
	Differential support	CMR,RTCM2.X,RTCM3.0,RTCM3.2
	Static format support	GNS, Rinex dual format static data
	RTK positioning accuracy	Plane: ±(8+1×10-6D) mm (D is the distance between the measured points) Elevation: ±(15+1×10-6D) mm (D is the distance between the measured points)
	Static positioning accuracy	Plane: ±(2.5+0.5×10¯6D) mm (D is the distance between the measured points) Elevation: ±(5+0.5×10¯6D) mm (D is the distance between the measured points)
	DGPS positioning accuracy	Plane accuracy: ±0.25m+1ppm;Elevation accuracy: ±0.50m+1ppm
	Initialization time	<10 seconds
	Initialization reliability	＞99.99%
	IMU tilt compensation	Additional horizontal pole tip uncertainty typically less than 10mm + 0.7 mm/° tilt down to 30° IMU tilt angle:0°~60°
communication	NFC Communication	Realizing close range (shorter than 10cm) automatic pair between receiver and controller (controller equipped NFC wireless communication module needed)
	WiFi	802.11b/g access point and client mode, can provide WiFi hotspot service
	Bluetooth	BLEBluetooth 4.0 standard, support for android, ios cellphone connection
	Wireless modem	Built-in radio, typically work range can be 8KM Radio repeater
	I/O port	5PIN LEMO external power port + RS232, 1 radio antenna interface, Type C , Micro SIM card
	frequency band:	410-470MHz
	Protocol	SOUTH,Farlink,TrimTalk,ZHD, HUACE
User Interface	Buttons	One button operation
User Interface	Indicators	Four indicate lights
Electrical physical properties	battery	Internal Li-on, 6800mAh, 7.4V
	Power Supply	9-25V DC, overvoltage protection
	size	135mm(Diameter)x84.75mm(Height)
	weight	0.97kg (battery included)
	material	Magnesium aluminum alloy shell
Environmental characteristics	Dust and water release	IP68 standard, protected from long time immersion to depth of 1m
	Storag	-55°C~+85°C
	Operating	-45℃~70℃
Specification
System	model	H6
	operating system	Android 8.1
	CPU	2.0 GHz eight-core processor
	Memory	3GB RAM
	Storage	32GB
Communication	Network	TDD/FDD-LTE 4G
	WiFi	802.11b/g access point and client mode, can provide WiFi hotspot service
	Bluetooth	V2.1+EDR/V3.0+HS/V4.1
	NFC	Support NFC IGRS
	USB	Mini USB, supports OTG
Electrical	Battery	7.4V, 3400mAh
	Battery life	12 hours
	Charging	< 4 hrs for full charge
Physical	size	206mm×85mm×40mm
	Weight	470g
	Operating temperature	-30℃ ~ +60℃
