Good price online

products details

Home > Products >
GNSS RTK Receiver
>
IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument
All Category

GNSS RTK Receiver

GIS Data Collector

Robotic Total Station

Electronic Theodolites

Laser Plummet

Automatic Level

Laser Distance Meters

3D Laser Scanner

UAV Drone Survey

Surpad 4.2 Software

Echo Sounder
Contact Us
Miss. Lili Zhou
yyi658731@gmail.com
wechat ChengDu-3987
Contact Now
IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument
  • name
  • name
  • name
  • name
  • name
  • name

IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument

Brand Name: CHCNAV
Model Number: E93
MOQ: 1 piece
Price: $2,900.00
Payment Terms: L/C, T/T
Detail Information
Product Description
Detail Information
Place of Origin:
China
Product Name:
RTK Receiver
Material:
Magnesium Alloy
Operating Language:
English
Application:
Land Surveying
Channels:
963 Channels
Weight:
0.73kg
GPS:
L1C/A,L2P,L2C,L5,L1C*
SBAS:
L1C/A,L5*
QZSS:
L1 、L2C、 L5
Glonass:
G1,G2,G3*
Galileos:
E1,E5b,E5a,E5 AltBoc*,E6c*
Protection Grade:
IP68
Supply Ability:
1 ~ 30 day
Highlight:

IMU Tilt gps gnss rtk

,

E93 gps gnss rtk

,

936 Channels gnss rtk antenna

Product Description

 IMU Tilt CHC Gps Rtk receiver 936 channels Surveying and Mapping Instrument E93 Gnss



IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument 0

IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument 1

IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument 2

Technical Parameters





Channel
963




Satellite Tracked
GPS L1CA/L1P/L1C/L2P/L2C/L5
GLONASS G1, G2, G3
Galileo E1, E5a, E5b, ALTBOC, E6
QZSS L1, L2 L5,
BeiDou B1I, B2I, B3I, B1C, B2a, B2b, ACEBOC
SBAS Ll, L5
Update rate
5 Hz, up to 50 Hz
Performance Specifications
Signal Reacquisition
< 1 sec
Hot Start
< 10 sec
Initialization Reliability
> 99.9%
Memory
8 GB
IMU
0~60°
Tilt compensation accuracy
10mm+0.7mm/°tilt (accuracy within 30°<2.5cm)

Static Accuracy
Horizontal:3mm + 1ppm
Vertical:5 mm + 1 ppm

RTK Accuracy
Horizontal:8 mm + 1 ppm
Vertical:15 mm + 1 ppm
Code Differential
Horizontal:0.4 m
SBAS Accuracy
Horizontal:0.8 m
Communication
7-pin
Connect to external power and radio
USB
For charging and data transmission
Cellular
Global 4G
Bluetooth
V4.1
WIFI
802.11 ac/n/b/g/n

WebUI
Update firmware, manage settings and
status, download data



Date formats
CNR input and out put
RTCM 2.x, RTCM 3.x input and output
NMEA 0183 output
HCN, HRC and RINEX 2.11, RINEX 3.02
NTRIP Client, NTRIP Caster
Electronic Bubble
Support
Dimensions
119 mm*119 mm * 85mm,0.73kg
Shock
Survive a 2 m pole drop on concrete floor 1.2 m free drop
interface
1 USB-TypeC interface, support charging, power supply, data download
SIM Card
NANO SIM
Cellular
Global 4G
Bluetooth
V2.1+EDR / V4.1 Dual Mode, Class 2
WIFI
802.11 ac/n/b/g/n
WebUI
Update firmware, manage settings and status, download data
Electronic Bubble
Support
Environment
Dustproof&Waterproof
IP67 (Customizable IP68)
Humidity
95% non-condense
Power Supply

Battery
Rechargeable, built-in Lithium-ion battery,7.2 V - 6800mAh
Voltage
9~28 V DC external power input
Working Time
Up to 15 hours
Internal Radio
Protocol
CHC, Transparent, TT450
Radio
RK radio, Built-in high-frequency 450-470MHz

Certifications



IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument 3



Company Profile

IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument 4


FAQ



1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),North America(4.00%),Eastern
Europe(4.00%). There are total about 11-20 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian



Our Service
IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument 5

Packing & Delivery
IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument 6
Tags:

base rover gps

gps rtk gnss

rtk survey equipment

Good price online

Products Details

Home > Products >
GNSS RTK Receiver
>
IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument
All Category

GNSS RTK Receiver

GIS Data Collector

Robotic Total Station

Electronic Theodolites

Laser Plummet

Automatic Level

Laser Distance Meters

3D Laser Scanner

UAV Drone Survey

Surpad 4.2 Software

Echo Sounder
IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument
  • name
  • name
  • name
  • name
  • name
  • name

IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument

Brand Name: CHCNAV
Model Number: E93
MOQ: 1 piece
Price: $2,900.00
Payment Terms: L/C, T/T
Detail Information
Product Description
Detail Information
Place of Origin:
China
Brand Name:
CHCNAV
Model Number:
E93
Product Name:
RTK Receiver
Material:
Magnesium Alloy
Operating Language:
English
Application:
Land Surveying
Channels:
963 Channels
Weight:
0.73kg
GPS:
L1C/A,L2P,L2C,L5,L1C*
SBAS:
L1C/A,L5*
QZSS:
L1 、L2C、 L5
Glonass:
G1,G2,G3*
Galileos:
E1,E5b,E5a,E5 AltBoc*,E6c*
Protection Grade:
IP68
Minimum Order Quantity:
1 piece
Price:
$2,900.00
Delivery Time:
30 work day
Payment Terms:
L/C, T/T
Supply Ability:
1 ~ 30 day
Highlight:

IMU Tilt gps gnss rtk

,

E93 gps gnss rtk

,

936 Channels gnss rtk antenna

Product Description

 IMU Tilt CHC Gps Rtk receiver 936 channels Surveying and Mapping Instrument E93 Gnss



IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument 0

IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument 1

IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument 2

Technical Parameters





Channel
963




Satellite Tracked
GPS L1CA/L1P/L1C/L2P/L2C/L5
GLONASS G1, G2, G3
Galileo E1, E5a, E5b, ALTBOC, E6
QZSS L1, L2 L5,
BeiDou B1I, B2I, B3I, B1C, B2a, B2b, ACEBOC
SBAS Ll, L5
Update rate
5 Hz, up to 50 Hz
Performance Specifications
Signal Reacquisition
< 1 sec
Hot Start
< 10 sec
Initialization Reliability
> 99.9%
Memory
8 GB
IMU
0~60°
Tilt compensation accuracy
10mm+0.7mm/°tilt (accuracy within 30°<2.5cm)

Static Accuracy
Horizontal:3mm + 1ppm
Vertical:5 mm + 1 ppm

RTK Accuracy
Horizontal:8 mm + 1 ppm
Vertical:15 mm + 1 ppm
Code Differential
Horizontal:0.4 m
SBAS Accuracy
Horizontal:0.8 m
Communication
7-pin
Connect to external power and radio
USB
For charging and data transmission
Cellular
Global 4G
Bluetooth
V4.1
WIFI
802.11 ac/n/b/g/n

WebUI
Update firmware, manage settings and
status, download data



Date formats
CNR input and out put
RTCM 2.x, RTCM 3.x input and output
NMEA 0183 output
HCN, HRC and RINEX 2.11, RINEX 3.02
NTRIP Client, NTRIP Caster
Electronic Bubble
Support
Dimensions
119 mm*119 mm * 85mm,0.73kg
Shock
Survive a 2 m pole drop on concrete floor 1.2 m free drop
interface
1 USB-TypeC interface, support charging, power supply, data download
SIM Card
NANO SIM
Cellular
Global 4G
Bluetooth
V2.1+EDR / V4.1 Dual Mode, Class 2
WIFI
802.11 ac/n/b/g/n
WebUI
Update firmware, manage settings and status, download data
Electronic Bubble
Support
Environment
Dustproof&Waterproof
IP67 (Customizable IP68)
Humidity
95% non-condense
Power Supply

Battery
Rechargeable, built-in Lithium-ion battery,7.2 V - 6800mAh
Voltage
9~28 V DC external power input
Working Time
Up to 15 hours
Internal Radio
Protocol
CHC, Transparent, TT450
Radio
RK radio, Built-in high-frequency 450-470MHz

Certifications



IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument 3



Company Profile

IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument 4


FAQ



1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),North America(4.00%),Eastern
Europe(4.00%). There are total about 11-20 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian



Our Service
IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument 5

Packing & Delivery
IMU Tilt CHC E93 Gnss Rtk Receiver 936 Channels antenna Surveying And Mapping Instrument 6
