IP67 Waterproof dumpy Automatic Level Measuring Instruments South NL32A

Brand Name: SOUTH
Model Number: NL-32A
MOQ: 1 set
Price: ＄160
Packaging Details: 35X25X20 cm
Payment Terms: T/T, L/C
Detail Information
Product Description
Detail Information
Place of Origin:
China
Product Name:
Automatic Level
Warranty:
1 Year
Temperature Range:
-20℃～50℃
Magnification:
32X
Objective Lens Aperture:
40mm
Error:
±1mm
Viewing Angle:
1°30′
Setting Accuracy:
±0.4″
Waterproof:
IP67
Dustproof:
IP67
Highlight:

IP67 Waterproof Automatic Level

,

South NL32A Automatic Level

,

IP67 Waterproof automatic dumpy level

Product Description

SOUTH NL32A AutomaticLevel Measuring Instrument







Product paramenters



Measurement standard deviation per kilometer round trip 1.0mm (shortest sighting distance0.6m)
DSZ3+FSImicrometer 0.3mm
Telescope imaging/magnification just as / 32×
Objective lens aperture 38mm
viewing angle 1°20′
Multiplying constant/Adding constant 100 / 0
Compensator working range ±15′
setting accuracy ±0.6″
Circular bubble accuracy 8′/2mm
Dividing value of dial 1°/1gon
temperature range -20℃～50℃
size 130mm×100mm×180mm
Waterproof and Dustproof  IP67



Product Features


Metal body dustproof and waterproof
32x HD Lens
See farther and clearer
Core compensation accuracy is guaranteed

IP67 Waterproof dumpy Automatic Level Measuring Instruments South NL32A 0IP67 Waterproof dumpy Automatic Level Measuring Instruments South NL32A 1

IP67 Waterproof dumpy Automatic Level Measuring Instruments South NL32A 2IP67 Waterproof dumpy Automatic Level Measuring Instruments South NL32A 3







IP67 Waterproof dumpy Automatic Level Measuring Instruments South NL32A 4
IP67 Waterproof dumpy Automatic Level Measuring Instruments South NL32A 5
Certifications

IP67 Waterproof dumpy Automatic Level Measuring Instruments South NL32A 6

Company Profile

IP67 Waterproof dumpy Automatic Level Measuring Instruments South NL32A 7


FAQ



1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),

North America(4.00%),Eastern Europe(4.00%). There are total about 11-20 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian



Our Service
IP67 Waterproof dumpy Automatic Level Measuring Instruments South NL32A 8

Packing & Delivery
IP67 Waterproof dumpy Automatic Level Measuring Instruments South NL32A 9
