Good price online

products details

Home > Products >
Automatic Level
>
38X Dumpy Optical Automatic Level Survey Measuring Instruments
All Category

GNSS RTK Receiver

GIS Data Collector

Robotic Total Station

Electronic Theodolites

Laser Plummet

Automatic Level

Laser Distance Meters

3D Laser Scanner

UAV Drone Survey

Surpad 4.2 Software

Echo Sounder
Contact Us
Miss. Lili Zhou
yyi658731@gmail.com
wechat ChengDu-3987
Contact Now
38X Dumpy Optical Automatic Level Survey Measuring Instruments
  • name
  • name
  • name
  • name
  • name
  • name

38X Dumpy Optical Automatic Level Survey Measuring Instruments

Brand Name: FOIF
Model Number: DSZ1
MOQ: 1 set
Price: ＄290
Packaging Details: 35X25X20 cm
Payment Terms: T/T, L/C
Detail Information
Product Description
Detail Information
Place of Origin:
China
Product Name:
Automatic Level
Warranty:
1 Year
Temperature Range:
-30℃～50℃
Magnification:
38X
Objective Lens Aperture:
50mm
Error:
0.7mm
Sensitivity Of Circular:
10′/2mm
Setting Accuracy:
±0.3″
Waterproof:
IPX6
Dustproof:
IPX6
Highlight:

dumpy Automatic Level

,

Automatic Level Instruments

,

38X auto level dumpy level

Product Description

38X Dumpy Optical Automatic Level Survey Measuring Instruments

Overview
50MM large diameter objective lens
Significantly increase the amount of light into the image clearer
Waterproof and dustproof grade IP55
Sealing mechanism waterproof and dustproof
Compensator and other places with sealing ring, metal body, anti-drop wear-resistant, bad weather can still work.
Built-in reading disc Stable reading
Millimetre accuracy
Standard deviation of measurement per kilometre round trip ≤ 1mm
38X high-definition imaging
See farther and work in a wider range than ordinary level meter Longer distance measurement, clearer imaging
Copper high-precision compensator
Compensator is made of copper sheet with longer swing arm, anti-drop, stable measurement, and can guarantee the reliable working of the instrument.


Error 1mm
Magnification 38x
Diameter of the objective 50mm
Angle of field of view 1°20''
Shortest sighting distance 0.3M
Multiplication constan 100
Compensator range ±15'
Setting accuracy ±0.3''
Bubble accuracy 20''/2MM
Image Erect
Warranty 1 year
Net weight 2kg



Products Description
38X Dumpy Optical Automatic Level Survey Measuring Instruments 0
38X Dumpy Optical Automatic Level Survey Measuring Instruments 1
38X Dumpy Optical Automatic Level Survey Measuring Instruments 2
38X Dumpy Optical Automatic Level Survey Measuring Instruments 3
Certifications

38X Dumpy Optical Automatic Level Survey Measuring Instruments 4

Company Profile

38X Dumpy Optical Automatic Level Survey Measuring Instruments 5


FAQ



1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),

North America(4.00%),Eastern Europe(4.00%). There are total about 11-20 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian



Our Service
38X Dumpy Optical Automatic Level Survey Measuring Instruments 6

Packing & Delivery
38X Dumpy Optical Automatic Level Survey Measuring Instruments 7



Tags:

auto level survey instrument

automatic level surveying

dumpy leveling
