Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision
  • name
  • name
  • name
  • name
  • name

Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision

Brand Name: DAD
Model Number: DE2A-L
MOQ: 1 piece
Price: $478.41
Payment Terms: L/C,T/T
Detail Information
Product Description
Detail Information
Place of Origin:
China
Supply Ability:
1 ~ 10 day
Highlight:

DE2A-L Laser Electronic Mapping

,

High Precision Laser Electronic Mapping

Product Description


Product Paramenters

Products Description

Model and Specification

DE2A-L

Telescope


Erect

Magnification

30x

Objective aperture

47mm

Field of view

1°30′

Shortest viewing distance

1m

Stadia ratio

100

Resolution

3.75″

Angle measurement

Angle measurement mode

Absolute angle encoder system

Minimum count

1″/5″/10″/20″

Angle units

DEG/MIL/GON

Accuracy

2″/5″/10″

Display

LCD

LCD double sides

compensator

Compensation range

±3′



Resolution

1″

Up laser point

Wavelength

635nm

Laser focusingpoint

5mm/100m

Deviation between laser focusing point and telescope collimation axis

≤5″

Valid optical distance

150m(Day)

Down Point type

Down Laser plummet

Precision of plate vial

30″/2mm

Precision of circular vial

8′/2mm

Working Temperature

-20鈩�~+50鈩�

Power

Battery

Chargeable NiMH battery

Voltage

6.0V

Instrument weight

6.5kg

Volume

180mm×166mm×355mm




Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision 0Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision 1Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision 2Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision 3Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision 4Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision 5Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision 6Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision 7Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision 8




Certifications



Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision 9
Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision 10

Company Profile
Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision 11

FAQ


1. who are we?
We are based in sichuan, China, start from 2016,sell to Africa(30.00%),Southeast Asia(16.00%),Mid East(11.00%),Eastern
Asia(10.00%),South America(10.00%),Central America(5.00%),South Asia(5.00%),Southern Europe(5.00%),North America(4.00%),Eastern
Europe(4.00%). There are total about 11-20 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
GNSS RTK,Total station,Level,Survey accessory,laser rangefinder

4. why should you buy from us not from other suppliers?
1.More than 20 years of experience in the trade field. 2.All products will have been strictly quality checked in factory before
sending out and all products have one year warranty.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian


Our Service
Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision 12

Packing & Delivery
Changzhou Geodetic Longitude And Latitude Laser Electronic Measuring And Mapping DE2A-L Upper And Lower Laser High Precision 13
Certifications
